150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines

China SHANGHAI PANDA MACHINERY CO.,LTD certification
China SHANGHAI PANDA MACHINERY CO.,LTD certification
The Candy Toffee Production Line produce and deliver very quick, very good quality, thanks for your cooperation!!

—— Justin

Trusted seller, on time delivery, professional customer's services pre and post sales. Thank you so much. Keep up the good work! We will purchase other Cookie Machine and Chip Baking Production Line soon!

—— Marcos

The Automatic Triple-Head Chocolate Pouring Production Line works very well, thanks a lot. Your productivity, service attitude, and sincerity of cooperation all make us very satisfied. We are a trusted partner.

—— Kevin

I'm Online Chat Now

150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines

150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines
150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines

Large Image :  150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines

Product Details:

Place of Origin: SHANGHAI, CHINA
Brand Name: PANDA MACHINERY
Certification: ISO ,CE
Model Number: PD150/300/450/600

Payment & Shipping Terms:

Minimum Order Quantity: 1Set
Price: USD40000-USD200000/SET
Packaging Details: Standard Exporting Wooden Boxes
Delivery Time: 35-60 Days
Payment Terms: T/T
Supply Ability: 5 Sets Per Month
Detailed Product Description
Production Name: Hard Candy Production Line Capacity: 150Kg/H, 300Kg/H, 450Kg/H, 600Kg/H
Application: All Kinds Of Hard Candy Advantage: Original Manufacture Competitive Price
High Light:

150kg/H Hard Candy Production Line

,

SS Candy Forming Machine

,

PLC Hard Candy Production Line

150Kg/H 300Kg/H 450Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines

150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 0

1.Brief Introduction:

Panda Hard Candy Production Line is an advanced equipment for producing various shapes and colors of hard candy. ideal equipment for continuous production of high quality single and double color hard candy.

High-degree automation ensures of stale production and saves time, labor force and occupation to serve purpose of reducing the cost



2.Hard Candy Production Process:

Sugar Melting--Storage Tank--Micro-Film Cooker--Depositing And Cooling--Packing



3.The Functions of Each Machine:

3.1 Sugar melting tank: heating sugar, glocose, water to 110 degrees.

3.2 Storage tank: storage the sugar syrup and and filting pure syrup.

3.3 Micro-film cooker: cooker the syrup again to 145 degrees for better taste, moisture is lower then 2%, suits for international standard.

3.4 Deposting and Cooling: depositing the sugar syrup into different candy mouds

3.5 Packing machine: various packing machine available.



4.Tips On The Hard Candy Production Line:

4.1 The whole line equipped the international motor: ABB motor, Danfoss invertor, Mitsubishi PLC control, servo motor, SS materials

4.2 Heating by steam or electric

4.3 Essence and pigment pump installed with the machine.

4.4 Various shapes hard candy can be produced by changing moulds

4.5 Candy size and weight effects the final output

4.6 One/ two colors/center fillied hard candy can be made

4.7 260 pieces candy moulds for the 150 type, 520 pieces for the 300 type



5.Technical Parameters:

Model PD150 PD300 PD450 PD600
Standard Output 150kg/h 300kg/h 450kg/h 600kg/h
Max.Candy Weight over 4 gram
Depositing Speed 40-45/min 40-45/min 40-45/min 40-45/min
Steam Requirement 0.2m³/min,
0.4-0.6Mpa
0.2m³/min,
0.4-0.6Mpa
0.2m³/min,
0.4-0.6Mpa
0.2m³/min
,0.4-0.6Mpa
Working Requirement Room Temperature: 20~25℃ Humidity: 55%
Total Power 18kw/380V 27kw/380V 34kw/380V 38kw/380V
Total Length 15m 17m 17m 20m
Total Weight 3500kg 4000kg 4500kg 5000kg



7.Hard Candy Processing Flow Chart:



Professional Hard candy production line 150kg / 300kg per hour Hard Candy Making Equipment / Machine Automatic 15 - 50kw

Professional Hard candy production line 150kg / 300kg per hour Hard Candy Making Equipment / Machine Automatic 15 - 50kw

150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 3



8.Machine Factory Fabrication Photos:


150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 4150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 5150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 6

8.Hard Candy Samples:

150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 7

150Kg/H 300Kg/H 600Kg/H Automatic Servo Drivng PLC Control Hard Candy Production Line Industry Plant Candy Machines 8


Professional Hard candy production line 150kg / 300kg per hour Hard Candy Making Equipment / Machine Automatic 15 - 50kw



Professional Hard candy production line 150kg / 300kg per hour Hard Candy Making Equipment / Machine Automatic 15 - 50kwProfessional Hard candy production line 150kg / 300kg per hour Hard Candy Making Equipment / Machine Automatic 15 - 50kwProfessional Hard candy production line 150kg / 300kg per hour Hard Candy Making Equipment / Machine Automatic 15 - 50kwProfessional Hard candy production line 150kg / 300kg per hour Hard Candy Making Equipment / Machine Automatic 15 - 50kwProfessional Hard candy production line 150kg / 300kg per hour Hard Candy Making Equipment / Machine Automatic 15 - 50kwProfessional Hard candy production line 150kg / 300kg per hour Hard Candy Making Equipment / Machine Automatic 15 - 50kw

9.Certification:

Cup cake production line muffin making processing machines cupcake forming machine cake cookies making machine

10.Contact Information:

Mob,Wechat,Whatsapp:+8613795369808 +8617162115888 Mr.Paul Wang Email: paul@pandamachinerysh.com

Mob/Wechat/Whatsapp:+8613127731236 Ms.Isabel Lee Email: isabel@pandamachinerysh.com

Websites:www.biscuitprocessingline.com www.pandamachinerycn.com www.pandamachinerysh.com
